Browse infrared cameras and related instruments by product family below, or send an enquiry to request a technical shortlist for your specific measurement parameters.
Explore Product Categories
Cameras
Hyperspectral & Multispectral
Spectroscopy
Infrared Optics & Testing
Instrument Catalogue
-
Spectral Devices MSDC Multispectral Drone Cameras (VIS-NIR)
The multispectral camera MSDC from Spectral Devices provides configurable VIS–NIR multispectral imaging for inspection and drone mapping. The MSDC payload pairs a 4 MP global-shutter CMOS with a PixHawk-ready package at about 660 g fully loaded. Band sets include RGB-NIR, agricultural NDVI/SAVI, and optional 8-band VIS or NIR configurations. OEMs and agronomy teams use this…
-
Spectral Devices MSC2 Multispectral Imaging Systems (VIS-NIR)
The multispectral camera MSC2 from Spectral Devices provides configurable VIS–NIR multispectral imaging for inspection and drone mapping. MSC2 systems pair the camera with spectrally matched LED illumination for synchronised multichannel capture. Band sets include RGB-NIR, agricultural NDVI/SAVI, and optional 8-band VIS or NIR configurations. OEMs and agronomy teams use this multispectral camera when they need…
-
Avio InfReC R550 High-Resolution LWIR Thermal Camera
The LWIR thermal camera R550 from Avio is a scientific thermal imager operating in the 8 – 14 µm band. It uses an uncooled microbolometer with 1280 × 960 Super Resolution output and frame rates up to 120 Hz. Published figures include NETD around 0.025°C at 30°C and measurement span -40°C to 2000°C (Pro). It…
-
Avio InfReC R450 Multi-Purpose LWIR Thermal Camera
The LWIR thermal camera R450 from Avio is a scientific thermal imager operating in the 8 – 14 µm band. It uses an uncooled microbolometer with 960 × 720 Super Resolution output and frame rates up to 40 Hz. Published figures include NETD around 0.025°C at 30°C and measurement span -40°C to 1500°C (Pro). It…
-
MKS Ophir Kamu Long-Range MWIR Thermal Cameras
The Kamu MWIR thermal cameras from MKS Ophir integrate long-range cooled MWIR optics for SXGA MWIR Cooled (1280×1024, 10 µm). Focal lengths span 21-420mm up to 60-1200mm at Constant f/4.0 for surveillance and defence observation. Integrators specify these MWIR thermal cameras when they need diffraction-limited MWIR zoom performance on cooled SXGA sensors. Overview: SXGA MWIR…
-
MKS Ophir LWIR Lenses for Uncooled Cameras
The LWIR lens range from MKS Ophir covers LWIR lenses for uncooled cameras matched to Uncooled VGA/XGA (10-12 µm). Available focal lengths include 15-75 mm and 15-300 mm continuous-zoom options at f/1.0–f/1.4 for surveillance, defence, and industrial thermal systems. Optical integrators choose this LWIR lens line when they need production IR optics matched to their…
-
MKS Ophir MWIR Lenses for Cooled Cameras
The MWIR lens range from MKS Ophir covers MWIR lenses for cooled cameras matched to Cooled SXGA/HD/VGA (10-15 µm). Available focal lengths include 21-420mm up to 50-1350mm at f/4.0 and f/5.5 for surveillance, defence, and industrial thermal systems. Optical integrators choose this MWIR lens line when they need production IR optics matched to their detector…
-
MKS Ophir SWIR Continuous Zoom Lenses
The infrared lens range from MKS Ophir covers SWIR continuous-zoom lenses matched to SWIR / NIR Detectors (0.7 – 1.7 µm). Available focal lengths include 25-250mm, 50-1000mm at Constant f/5.5 for surveillance, defence, and industrial thermal systems. Optical integrators choose this infrared lens line when they need production IR optics matched to their detector format.…
-
CI Systems MSS-SWIR Mobile Signal Simulator
The missile signal simulator MSS-SWIR from CI Systems generates controlled SWIR signatures to test missile approach warning systems in the lab or field. It provides a wide illumination field (over 50°) with typical radiant intensity of 1–10 mW/sr and 5 ms temporal resolution for dynamic threat-scenario validation. Defence and EO test teams use this missile…
-
CI Systems MSS-UV Mobile Signal Simulator
The missile signal simulator MSS-UV from CI Systems generates controlled signatures to test missile approach warning systems in the lab or field. It operates in 265 ± 5 nm (UV-C) with > 7° Illumination Field, radiant output 1-10 mWatt/sr (Typical), and 5 msec temporal resolution for dynamic threat-scenario validation. Defence and EO test teams use…
-
CI Systems MSS-IR Mobile Signal Simulator
The missile signal simulator MSS-IR from CI Systems generates controlled signatures to test missile approach warning systems in the lab or field. It operates in Single (NIR to LWIR) or Dual MWIR Band with > 50° (Single) or > 7° (Dual), radiant output 1-10 mWatt/sr (Typical), and 5 msec temporal resolution for dynamic threat-scenario validation.…
-
CI Systems C-MSS Collimated Missile Signature Simulator
The missile signal simulator C-MSS from CI Systems generates collimated missile signatures to test missile approach warning systems in the lab or field. It operates in MWIR with 3.5 mrad Source / 40 mrad Background, radiant output > 20 nW/cm² (Controlled Radiance), and 5 msec temporal resolution for dynamic threat-scenario validation. Defence and EO test…
-
CI Systems IRTS-L Laser-Based Infrared Threat Simulator
The missile signal simulator IRTS-L from CI Systems projects controlled threat signatures to test missile approach warning systems in the lab or field. It operates in 3.95 µm and/or 4.6 µm (MWIR) with > 35H x 14V mrad Divergence, radiant output up to 1.2 kW/sr, and 5 msec temporal resolution for dynamic threat-scenario validation. Defence…
-
CI Systems SWTS SWIR Threat Simulator
The missile signal simulator SWTS from CI Systems projects controlled threat signatures to test missile approach warning systems in the lab or field. It operates in 1550 nm (BW ± 50 nm) with 10° Circular, radiant output > 16 W/Sr, and 10 kHz temporal resolution for dynamic threat-scenario validation. Defence and EO test teams use…
-
CI Systems UVTS UV Threat Simulator
The missile signal simulator UVTS from CI Systems projects controlled threat signatures to test missile approach warning systems in the lab or field. It operates in 270 ± 10 nm with 5° Circular, radiant output > 20 W/Sr, and 5 msec temporal resolution for dynamic threat-scenario validation. Defence and EO test teams use this missile…
-
CI Systems IRTS-L & UVTS Combined Threat Simulator
The missile signal simulator IRTS-L and UVTS from CI Systems projects controlled threat signatures to test missile approach warning systems in the lab or field. It operates in Multispectral (MWIR and UV-C) with Configurable Multi-Sensor, radiant output > 20 W/Sr (UV) / 1.2 KW/str (IR), and 5 msec temporal resolution for dynamic threat-scenario validation. Defence…
-
CI Systems Pan/Tilt Gimbal for Electro-Optical Testing
The Pan/Tilt Gimbal from CI Systems mounts electro-optical devices in automated test benches. Yoke apertures span 12″, 15″, 19″, 22″, 24″, 32″, 37″, accuracy options 50/64 arcsec (Std) | 6/30 arcsec (High Accuracy), travel ±140° (Azimuth and Elevation), and loads to 50 kg (Optional up to 150 kg) for repeatable azimuth/elevation positioning. Test engineers use…
-
CI Systems CFT Compact Field Tester
The CFT infrared compact field tester from CI Systems is a refractive collimator for portable EO payload checks from 400 nm to 12 µm (Model Dependent). Clear apertures of 1.9 to 4.9 inches (48 – 125 mm) and focal lengths of 250 mm to 500 mm support field MTF and alignment work. Field technicians rely…
-
CI Systems WFOV IR Test System
The WFOV IR test system from CI Systems is a wide-field refractive tester covering 0.9 µm to 12 µm (SWIR, MWIR, LWIR). With clear apertures of 70 mm or 100 mm and FOV around 11° to 15° (custom up to 65°), it supports SWIR/MWIR/LWIR sensor evaluation. EO labs use this IR test system when they…
-
CI Systems ILET Electro-Optical Tester
The ILET collimator from CI Systems is a reflective off-axis parabolic collimator for testing electro-optical payloads, imagers, and sensors from 0.4 µm to 15 µm. Clear apertures of 4–6 inches, focal lengths of 15–40 inches, and diffraction-limited on-axis performance support repeatable MTF and alignment measurements. Optical test engineers rely on this ILET collimator when they…
-
CI Systems METS Modular Electro-Optical Test System
The electro-optical test system METS from CI Systems is a modular reflective collimator for large-aperture payload testing from 0.4 µm to 15 µm. Clear apertures of 8 to 25 inches, focal lengths of 40 to 250 inches, and wavefront quality λ/25 RMS at 633 nm support MTF, boresight, and radiometric measurements. Optical test facilities specify…
-
CI Systems SR-33N Integrated Extended Area Blackbody
The blackbody SR-33N from CI Systems is an extended-area radiation source for infrared sensor calibration over 0°C to 100°C. Emitter formats include 4×4 inches or 7×7 inches, with emissivity 0.98 ± 0.02 and stability 0.01°C, for laboratory and production EO test. Calibration labs use this blackbody when they need a uniform, stable IR source matched…
-
CI Systems SR-800N-SE Spherical Aperture Blackbody
The blackbody SR-800N-SE from CI Systems is an extended-area radiation source for infrared sensor calibration over 5°C to 85°C. Emitter formats include 4, 7, or 12 inches (Spherical Dome), with emissivity 0.98 ± 0.02 and stability ±0.003°C (ΔT≤10°C), for laboratory and production EO test. Calibration labs use this blackbody when they need a uniform, stable…
-
CI Systems SR-200N High-Temperature Cavity Blackbody
The high-temperature blackbody SR-200N from CI Systems is a cavity radiation source for electro-optical calibration from 50°C to 1200°C. With a 1-inch cavity, emissivity of 0.99 ± 0.01, and stability around ±0.50°C, it supports laboratory and production test of infrared sensors and imagers. Calibration labs specify this high-temperature blackbody when they need a stable cavity…
